Dual Way Digital UHF Wireless Microphone with 2 Metal Handhelds (FB-U09) Freeboss

₦41,889
Brand:GENERIC
Product Code: FB-U09
Stock In Stock

Overview

Dual Way Digital UHF Wireless Microphone with 2 Metal Handhelds (FB-U09) Freeboss   FB-U09    UHF Wireless Microphone Dual Way Digital UHF Wir...

Available Options

Dual Way Digital UHF Wireless Microphone with 2 Metal Handhelds (FB-U09) Freeboss



FB-U09

   UHF Wireless Microphone Dual Way Digital UHF Wireless Microphone with 2 Metal Handhelds


Black Color:

FB-U09 01  Wireless Microphones

Gold Color:

FB-U09 01 Wireless Microphones

Silver Color:

FB-U09 01 Wireless Microphones



1. Key Point:

    1) UHF Band Fixed Frequency(653.50MHz,643.50MHz)

    2) Transmitter: 2 pcs Metal handhled microphones

    3) Receiver: Metal Box,ON/OFF Knob,Individual Volume Knob, AF/RF Indicator

    4) Special digital launch receiving circuit, strongly improve S/N ratio, high fidelity reduction pick up sound.

    5) Digital transmit receive encryption,stop all external signal interference.

    6) Set special arbitrary selection of 8 kinds effects sound output,suitable for all kinds occasions and performance activities.

             (0: standard  1: Boost  2: Treble  3: Pop  4: Rock  5: Classic  6: Jazz  7: Dance  8: R&B)

    7) Two XLR individual outputs and one 1/4"" Mixed output.

    8) Range: 30-50 meters , Suit for karaoke, speaking, party, etc.

    9) battery: 4*AA

8Kinds effects:
FB-U09 11  Wireless Microphones
Packing list:
FB-U09 41  Wireless Microphones

Working Range:

FB-U09 12  Wireless Microphones

2.Product Description:

  • Stability: 0.005% (-10-50)

  • Deviation: 40KHz

  • S/N: 96db

  • Distortion:0.5%@1KHz

  • Frequency Response: 30Hz-20KHz

3. Receiver :

Receiver front panel function:

1.) Power Switch:

   A)  Link the power adapter to receiver power socket,then link the power adapter to 220V power.

   B)  Press the receiver power button,power indicator is on,the receiver is on "working" status.

2.) AF Led Indictaor

     when RF indicator is on, microphone A/B power is on

   A) Microphone A/B pick up the sound, the AF light is on

   B) no sound is picked up, the AF light is off.

3.) RF Led Indictaor

    when the receiver is on "working" status,

   A) Microphone A/B no power, left/right RF light is off

   B) Microphone A/B is on, left/right RF light is on

4) Backlit Screen:  the screen will not change.

5.) Effect Screen:

     Display the number of the present effect.

6.) Effect Choose Button:

     Press the button, the number will change from 0 to 8. You can choose the effect according to the number. (0: standard  1: Boost 2: Treble 3: Pop 4: Rock 5: Classic 6: Jazz 7: Dance 8: R&B)

7.) Volume Knob:

     clockwise: volume from low to high

     anticlockwise: volume from high to low.

FB-U09 21  Wireless Microphones



Receiver back panel function:

1) Mic A and Mic B XLR socket:

A.) Need XLR cable:(not included in the package)

B.) From the socket,

a) you can link the receiver to audio mixer

b) then you can controld the microphone A  or microphone B separately.

2) Mix out socket:

A.) Need 6.35mm plug cable.(included in the package)

B.) From the socket,

a) you can link the receiver to amplifer/speaker,etc.

b) you only can control the microphone A and B together.

FB-U09 22  Wireless Microphones

Power adapter:

1) EU PLUG

2) US PLUG

3) PLUG adapter

FB-U09 33  Wireless Microphones







4. Transmitter:

  • Capsule: Professional Audio Dynamic Capsul

  • Transmitting power:<=10dbm

  • Frequency stabilization:+-0.005%

  • Battery Two-pieces battery of 1.5

Material:

Metal handheld, Comfort and smooth handling experience with elegant appearance.

Microphone head

Polygon design to prevent rolling.

Cartridge:

1) Type: Moving coil

2) Polar pattern: Cardioid

Low-LED:

Battery low power LED indicator:

     1)Red led light on: enough power

     2)Red led light flash: low power

FB-U09 31  Wireless Microphones



FB-U09 32  Wireless Microphones



FB-U09 23  Wireless Microphones

5. Application
FB-U09 43  Wireless Microphones

FB-U09 42  Wireless Microphones

6. Packing Pictures:

1) Microphone                   2pcs

2) Receiver                        1pc

3) Audio cabel                   1pc

4) Power adapter              1pc

5) Owner's manual            1pc

6)1.5V Battery  4pcs (Pls note: Due to transportation reasons, the battery is not issued with the goods, please purchase by yourself, tks!)

FB-U09 51  Wireless Microphones


FB-U09 20-1 Wireless Microphones



Please Note:

Please confirm the frequency is ok for you.

If you need other frequency, please tell us before you order.


HOW TO USE Wireless Microphone:

  1) 6.35 plug cable to audio mixer (there is one piece cable in the package)



3 MIX  01

 2) 6.35 plug cable to audio mixer (there is one piece cable in the package)

3 MIX  02

 3) 6.35 plug cable to amplifier (there is one piece cable in the package)

3 MIX  03

4) 6.35 plug cable to amplifier (there is one piece cable in the package)

3 MIX  04

5) 6.35 plug cable to amplifier speaker (there is one piece cable in the package)

3 MIX  05









Aliexpress
Brand Name: FREEBOSS
Set Type: Transmitter Sets
Application: KTV, Talk show ,Performance ,Entertainment
Communication: Wireless
Transducer: Dynamic Microphone
Use: Karaoke Microphone
Style: Handheld Microphone
Polar Patterns: Cardioid
Cartridge: Dynamic
Model Number: FB-U09
Package: Yes
Tube Material: Metal
Carrier frequency: UHF653.50MHz,643.50MHz
Receiver Material: metal box, plastic front panel
Working range: 50M(Without obstacle)
Working temperature range: -10~40℃
Warranty: 1 year
